MBRB30H80CT-1G
RoHS
/
Package TO-262-3 Long Leads, I2Pak, TO-262AA
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 80V I2PAK
PDF
/
Buying Options
Total Price: USD $0.79
Unit Price: USD $0.792
≥1 USD $0.792
Inventory: 1173
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 1 week ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-262-3 Long Leads, I2Pak, TO-262AA
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tube
Published 2009
Series SWITCHMODE?
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 150°C
Min Operating Temperature -20°C
Additional Feature LOW POWER LOSS
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 3
Qualification Status Not Qualified
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 250μA @ 80V
Voltage - Forward (Vf) (Max) @ If 780mV @ 15A
Max Reverse Leakage Current 250μA
Operating Temperature - Junction -20°C~150°C
Max Surge Current 240A
Application EFFICIENCY
Max Reverse Voltage (DC) 80V
Average Rectified Current 15A
Number of Phases 1
Diode Configuration 1 Pair Common Cathode
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
