MBR2030CTL
RoHS
/
Package TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
SWITCHMODE? Tube Through Hole Schottky Diode Array 520mV @ 10A 10A 580mV 500pF
PDF
/
Buying Options
Total Price: USD $18.24
Unit Price: USD $18.24475
≥1 USD $18.24475
≥10 USD $14.9701
≥100 USD $14.50175
≥500 USD $14.03435
≥1000 USD $13.56695
Inventory: 8408
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 1 day ago)
Physical
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Supplier Device Package TO-220AB
Technical
Packaging Tube
Published 2006
Series SWITCHMODE?
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Capacitance 500pF
Voltage - Rated DC 30V
Current Rating 20A
Base Part Number MBR2030CT
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 5mA @ 30V
Voltage - Forward (Vf) (Max) @ If 520mV @ 10A
Max Reverse Leakage Current 5mA
Operating Temperature - Junction -65°C~175°C
Max Surge Current 150A
Voltage - DC Reverse (Vr) (Max) 30V
Current - Average Rectified (Io) 10A
Forward Voltage 580mV
Max Reverse Voltage (DC) 30V
Average Rectified Current 10A
Peak Non-Repetitive Surge Current 150A
Diode Configuration 1 Pair Common Cathode
Max Forward Surge Current (Ifsm) 150A
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
