DAP222T1
RoHS
/
Package SC-75, SOT-416
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Tape & Reel (TR) Surface Mount Standard 1Pair Common Anode Diode Array 1.2V @ 100mA 100mA 150mW 10ns
PDF
/
Buying Options
Total Price: USD $0.48
Unit Price: USD $0.4826
≥1 USD $0.4826
≥10 USD $0.39615
≥100 USD $0.3838
≥500 USD $0.37145
≥1000 USD $0.3591
Inventory: 9099
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 1 week ago)
Physical
Mounting Type Surface Mount
Package / Case SC-75, SOT-416
Surface Mount YES
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Published 2004
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Additional Feature ULTRA HIGH SPEED SWITCHING
HTS Code 8541.10.00.70
Capacitance 3.5pF
Subcategory Rectifier Diodes
Voltage - Rated DC 80V
Max Power Dissipation 150mW
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Reach Compliance Code not_compliant
Current Rating 100mA
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number DAP222
Pin Count 3
Qualification Status Not Qualified
Number of Elements 2
Element Configuration Common Anode
Speed Small Signal =< 200mA (Io), Any Speed
Diode Type Standard
Current - Reverse Leakage @ Vr 100nA @ 70V
Voltage - Forward (Vf) (Max) @ If 1.2V @ 100mA
Max Reverse Leakage Current 100nA
Operating Temperature - Junction 150°C Max
Max Surge Current 2A
Output Current-Max 0.1A
Current - Average Rectified (Io) 100mA DC
Max Reverse Voltage (DC) 80V
Average Rectified Current 100mA
Reverse Recovery Time 10 ns
Non-rep Pk Forward Current-Max 2A
Diode Configuration 1 Pair Common Anode
Recovery Time 4 ns
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
