MSAD60-16
RoHS
/
Package D1
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Diode 1.6KV 60A 3-Pin Case D1
PDF
/
Inventory: 3035
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Package / Case D1
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Bulk
Published 2011
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish TIN LEAD
Max Operating Temperature 150°C
Min Operating Temperature -40°C
Additional Feature UL RECOGNIZED
HTS Code 8541.10.00.80
Terminal Position UPPER
Terminal Form UNSPECIFIED
Pin Count 3
Number of Elements 2
Element Configuration Common Anode
Speed Standard Recovery >500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 5mA @ 1600V
Voltage - Forward (Vf) (Max) @ If 1.3V @ 200A
Case Connection ISOLATED
Forward Current 60A
Application GENERAL PURPOSE
Voltage - DC Reverse (Vr) (Max) 1600V
Forward Voltage 1.3V
Max Reverse Voltage (DC) 1.6kV
Average Rectified Current 60A
Number of Phases 1
Peak Reverse Current 5mA
Max Repetitive Reverse Voltage (Vrrm) 1.6kV
Peak Non-Repetitive Surge Current 1.15kA
Diode Configuration 1 Pair Common Anode
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
