CPT30045
RoHS
/
Package MD3CC
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE MODULE 45V 150A 2TOWER
PDF
/
Inventory: 7473
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Package / Case MD3CC
Number of Pins 3
Supplier Device Package Twin Tower
Technical
Packaging Bulk
Published 2012
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 175°C
Min Operating Temperature -55°C
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 4mA @ 45V
Voltage - Forward (Vf) (Max) @ If 760mV @ 200A
Forward Current 300A
Voltage - DC Reverse (Vr) (Max) 45V
Current - Average Rectified (Io) 150A
Forward Voltage 760mV
Max Reverse Voltage (DC) 45V
Average Rectified Current 150A
Peak Reverse Current 4mA
Max Repetitive Reverse Voltage (Vrrm) 45V
Peak Non-Repetitive Surge Current 2kA
Diode Configuration 1 Pair Common Cathode
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
