BAT54ADW-TP
RoHS
RoHS compliant
RoHS compliantPackage 6-TSSOP, SC-88, SOT-363
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 30V SOT363
PDF
/
Buying Options
Total Price: USD $0.35
Unit Price: USD $0.352
≥1 USD $0.352
≥10 USD $0.27192
≥100 USD $0.163152
≥500 USD $0.151096
≥1000 USD $0.102749
Inventory: 1266
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Diode Configuration 2 Pair Common Anode
Rep Pk Reverse Voltage-Max 30V
Reverse Recovery Time 5ns
Current - Average Rectified (Io) 200mA DC
Voltage - DC Reverse (Vr) (Max) 30V
Output Current-Max 0.2A
Operating Temperature - Junction -65°C~125°C
Voltage - Forward (Vf) (Max) @ If 1V @ 100mA
Current - Reverse Leakage @ Vr 2μA @ 25V
Diode Type Schottky
Speed Small Signal =< 200mA (Io), Any Speed
Power Dissipation-Max 0.2W
Number of Elements 4
Operating Temperature (Max) 125°C
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G6
Pin Count 6
Base Part Number BAT54ADW
Time@Peak Reflow Temperature-Max (s) 10
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
HTS Code 8541.10.00.70
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2008
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case 6-TSSOP, SC-88, SOT-363
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
