BAS40DW-06-TP
RoHS
RoHS compliant
RoHS compliantPackage 6-TSSOP, SC-88, SOT-363
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 40V SOT363
PDF
/
Buying Options
Total Price: USD $0.41
Unit Price: USD $0.4136
≥1 USD $0.4136
≥10 USD $0.31856
≥100 USD $0.191224
≥500 USD $0.177021
≥1000 USD $0.120375
Inventory: 1180
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Surface Mount
Package / Case 6-TSSOP, SC-88, SOT-363
Surface Mount YES
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
HTS Code 8541.10.00.70
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 10
Base Part Number BAS40DW-06
Pin Count 6
JESD-30 Code R-PDSO-G6
Qualification Status Not Qualified
Operating Temperature (Max) 125°C
Number of Elements 4
Power Dissipation-Max 0.2W
Speed Small Signal =< 200mA (Io), Any Speed
Diode Type Schottky
Current - Reverse Leakage @ Vr 200nA @ 30V
Voltage - Forward (Vf) (Max) @ If 1V @ 40mA
Operating Temperature - Junction -55°C~125°C
Output Current-Max 0.2A
Voltage - DC Reverse (Vr) (Max) 40V
Current - Average Rectified (Io) 200mA
Reverse Recovery Time 5ns
Rep Pk Reverse Voltage-Max 40V
Diode Configuration 2 Pair Common Anode
Compliance
RoHS Status ROHS3 Compliant
