MDNA380P2200KC
RoHS
/
Package Y1-CU
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
BIPOLAR MODULE - DIODE Y1-CU
PDF
/
Inventory: 6932
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Reverse Current-Max 500μA
Diode Configuration 1 Pair Series Connection
Non-rep Pk Forward Current-Max 10100A
Rep Pk Reverse Voltage-Max 2200V
Number of Phases 1
Current - Average Rectified (Io) 380A
Voltage - DC Reverse (Vr) (Max) 2200V
Application HIGH VOLTAGE
Operating Temperature - Junction -40°C~150°C
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 1.05V @ 300A
Current - Reverse Leakage @ Vr 500μA @ 2.2kV
Diode Type Standard
Speed Standard Recovery >500ns, > 200mA (Io)
Power Dissipation-Max 1140W
Number of Elements 2
Operating Temperature (Max) 150°C
JESD-30 Code R-PUFM-X3
Reference Standard IEC-60747
Terminal Form UNSPECIFIED
Terminal Position UPPER
Additional Feature LOW LEAKAGE CURRENT, PD-CASE, UL RECOGNIZED
ECCN Code EAR99
Number of Terminations 3
Part Status Active
Physical
Diode Element Material SILICON
Surface Mount NO
Package / Case Y1-CU
Mounting Type Chassis Mount
Supply Chain
Factory Lead Time 28 Weeks
