MDD44-14N1B
RoHS
RoHS compliant
RoHS compliantPackage TO-240AA
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE MODULE 1.4KV 64A TO240AA
PDF
/
Buying Options
Total Price: USD $24.24
Unit Price: USD $24.244
≥1 USD $24.244
≥10 USD $21.54504
≥100 USD $18.844144
≥500 USD $16.08031
Inventory: 90
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Package / Case TO-240AA
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Bulk
Published 2012
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Max Operating Temperature 150°C
Min Operating Temperature -40°C
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Position UPPER
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MDD44
Pin Count 3
Qualification Status Not Qualified
Number of Elements 2
Speed Standard Recovery >500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 10mA @ 1400V
Voltage - Forward (Vf) (Max) @ If 1.6V @ 200A
Case Connection ISOLATED
Output Current-Max 59A
Application GENERAL PURPOSE
Voltage - DC Reverse (Vr) (Max) 1400V
Forward Voltage 1.6V
Max Reverse Voltage (DC) 1.4kV
Average Rectified Current 64A
Number of Phases 1
Peak Non-Repetitive Surge Current 1.3kA
Non-rep Pk Forward Current-Max 1150A
Reverse Voltage 1.4kV
Diode Configuration 1 Pair Series Connection
Compliance
RoHS Status ROHS3 Compliant
