MDD255-18N1
RoHS
RoHS compliant
RoHS compliantPackage Y1-CU
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE MODULE 1.8KV 270A Y1-CU
PDF
/
Inventory: 9355
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Diode Configuration 1 Pair Series Connection
Reverse Voltage 1.8kV
Non-rep Pk Forward Current-Max 9500A
Peak Non-Repetitive Surge Current 10.2kA
Number of Phases 1
Average Rectified Current 270A
Max Reverse Voltage (DC) 1.8kV
Forward Voltage 1.4V
Voltage - DC Reverse (Vr) (Max) 1800V
Application GENERAL PURPOSE
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 1.4V @ 600A
Current - Reverse Leakage @ Vr 30mA @ 1800V
Diode Type Standard
Speed Standard Recovery >500ns, > 200mA (Io)
Number of Elements 2
Qualification Status Not Qualified
Base Part Number MDD255
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UPPER
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Min Operating Temperature -40°C
Max Operating Temperature 150°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2004
Packaging Bulk
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case Y1-CU
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
Supply Chain
Factory Lead Time 28 Weeks
