MDD250-16N1
RoHS
RoHS compliant
RoHS compliantPackage Y2-DCB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
IXYS MDD250-16N1, Dual Diode Module, Series, 1600V 290A, 3-Pin Y2 DCB
PDF
/
Inventory: 9772
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Chassis Mount, Panel, Screw
Mounting Type Chassis Mount
Package / Case Y2-DCB
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Bulk
Published 2000
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Max Operating Temperature 150°C
Min Operating Temperature -40°C
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Position UPPER
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MDD250
Qualification Status Not Qualified
Number of Elements 2
Speed Standard Recovery >500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 40mA @ 1600V
Voltage - Forward (Vf) (Max) @ If 1.3V @ 600A
Case Connection ISOLATED
Forward Current 290A
Application GENERAL PURPOSE
Voltage - DC Reverse (Vr) (Max) 1600V
Forward Voltage 1.3V
Max Reverse Voltage (DC) 1.6kV
Average Rectified Current 290A
Number of Phases 1
Peak Reverse Current 40mA
Max Repetitive Reverse Voltage (Vrrm) 1.6kV
Peak Non-Repetitive Surge Current 11.7kA
Reverse Voltage 1.6kV
Diode Configuration 1 Pair Series Connection
Dimensions
Height 32mm
Length 116mm
Width 60mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
