HTZ150C6K
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE MODULE 6KV 3A
PDF
/
Inventory: 9131
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Diode Configuration 1 Pair Series Connection
Reverse Voltage 6kV
Peak Non-Repetitive Surge Current 100A
Number of Phases 1
Average Rectified Current 3A
Max Reverse Voltage (DC) 6kV
Forward Voltage 6V
Voltage - DC Reverse (Vr) (Max) 6000V
Application HIGH VOLTAGE
Output Current-Max 3A
Voltage - Forward (Vf) (Max) @ If 6V @ 2A
Current - Reverse Leakage @ Vr 500μA @ 6000V
Diode Type Standard
Speed Standard Recovery >500ns, > 200mA (Io)
Number of Elements 2
Qualification Status Not Qualified
Pin Count 3
Base Part Number HTZ150
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UPPER
HTS Code 8541.10.00.80
Min Operating Temperature -40°C
Max Operating Temperature 180°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2002
Packaging Bulk
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case Module
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
