DSSK70-008AR
RoHS
RoHS compliant
RoHS compliantPackage ISOPLUS247?
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 80V 35A
PDF
/
Buying Options
Total Price: USD $7.43
Unit Price: USD $7.42995
≥1 USD $7.42995
≥10 USD $6.09615
≥100 USD $5.9052
≥500 USD $5.7152
≥1000 USD $5.52425
Inventory: 10007
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 28 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case ISOPLUS247?
Number of Pins 247
Diode Element Material SILICON
Technical
Packaging Tube
Published 2005
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 175°C
Min Operating Temperature -55°C
Additional Feature FREE WHEELING DIODE
HTS Code 8541.10.00.80
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 3
JESD-30 Code R-XSIP-T3
Qualification Status Not Qualified
Number of Elements 2
Power Dissipation-Max 190W
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 4mA @ 80V
Voltage - Forward (Vf) (Max) @ If 760mV @ 35A
Case Connection ISOLATED
Max Reverse Leakage Current 4mA
Operating Temperature - Junction -55°C~175°C
Max Surge Current 600A
Application GENERAL PURPOSE
Forward Voltage 760mV
Max Reverse Voltage (DC) 80V
Average Rectified Current 35A
Number of Phases 1
Peak Non-Repetitive Surge Current 600A
Diode Configuration 1 Pair Common Cathode
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
