DSEP2X31-06B
RoHS
RoHS compliant
RoHS compliantPackage SOT-227-4, miniBLOC
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE MODULE 600V 30A SOT227B
PDF
/
Buying Options
Total Price: USD $22.82
Unit Price: USD $22.8209
≥1 USD $22.8209
≥10 USD $18.72545
≥100 USD $18.14025
≥500 USD $17.55505
≥1000 USD $16.96985
Inventory: 1004
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 28 Weeks
Physical
Mount Chassis Mount, Panel, Screw
Mounting Type Chassis Mount
Package / Case SOT-227-4, miniBLOC
Number of Pins 4
Supplier Device Package SOT-227B
Technical
Packaging Tube
Published 2000
Series HiPerFRED?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 150°C
Min Operating Temperature -40°C
Base Part Number DSEP2X
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 250μA @ 600V
Voltage - Forward (Vf) (Max) @ If 2.49V @ 30A
Forward Current 30A
Max Surge Current 250A
Voltage - DC Reverse (Vr) (Max) 600V
Current - Average Rectified (Io) 30A
Forward Voltage 3.16V
Max Reverse Voltage (DC) 600V
Average Rectified Current 30A
Reverse Recovery Time 30 ns
Peak Reverse Current 250μA
Max Repetitive Reverse Voltage (Vrrm) 600V
Peak Non-Repetitive Surge Current 250A
Reverse Voltage 600V
Diode Configuration 2 Independent
Max Forward Surge Current (Ifsm) 250A
Recovery Time 30 ns
Dimensions
Height 12.22mm
Length 38.23mm
Width 25.42mm
Compliance
RoHS Status ROHS3 Compliant
