DSEP2X25-12C
RoHS
RoHS compliant
RoHS compliantPackage SOT-227-4, miniBLOC
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
IXYS SEMICONDUCTOR DSEP2X25-12CDIODE, FAST, 50A, SOT-227B
PDF
/
Buying Options
Total Price: USD $34.53
Unit Price: USD $34.52632
≥1 USD $34.52632
≥10 USD $32.572
Inventory: 17
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 28 Weeks
Physical
Mount Chassis Mount, Panel, Screw
Mounting Type Chassis Mount
Package / Case SOT-227-4, miniBLOC
Number of Pins 4
Diode Element Material SILICON
Technical
Packaging Tube
Published 2011
Series HiPerDynFRED?
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
ECCN Code EAR99
Terminal Finish Nickel (Ni)
Max Operating Temperature 150°C
Min Operating Temperature -40°C
Additional Feature FREE WHEELING DIODE, LOW LEAKAGE CURRENT, SNUBBER DIODE, UL RECOGNIZED
Subcategory Other Diodes
Terminal Position UPPER
Terminal Form UNSPECIFIED
Base Part Number DSEP2X
Pin Count 4
Number of Elements 4
Power Dissipation-Max 210W
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 250μA @ 1200V
Voltage - Forward (Vf) (Max) @ If 4.71V @ 25A
Case Connection ISOLATED
Forward Current 25A
Max Surge Current 250A
Application SOFT RECOVERY
Voltage - DC Reverse (Vr) (Max) 1200V
Forward Voltage 5.92V
Max Reverse Voltage (DC) 1.2kV
Average Rectified Current 25A
Number of Phases 1
Reverse Recovery Time 15 ns
Peak Reverse Current 250μA
Max Repetitive Reverse Voltage (Vrrm) 1.2kV
Peak Non-Repetitive Surge Current 250A
Reverse Voltage 1.2kV
Diode Configuration 2 Independent
Max Forward Surge Current (Ifsm) 250A
Recovery Time 20 ns
Dimensions
Height 12.22mm
Length 38.23mm
Width 25.42mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
