DSEI2X61-12B
RoHS
RoHS compliant
RoHS compliantPackage SOT-227-4, miniBLOC
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
IXYS SEMICONDUCTOR DSEI2X61-12BDIODE, FAST, 104A, SOT-227B
PDF
/
Buying Options
Total Price: USD $20.14
Unit Price: USD $20.1362
≥1 USD $20.1362
≥10 USD $16.5224
≥100 USD $16.0056
≥500 USD $15.48975
≥1000 USD $14.97295
≥3000 USD $13.42445
Inventory: 7712
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 28 Weeks
Physical
Mount Chassis Mount, Panel, Screw
Mounting Type Chassis Mount
Package / Case SOT-227-4, miniBLOC
Number of Pins 8
Supplier Device Package SOT-227B
Technical
Packaging Tube
Published 2000
Series FRED
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Max Operating Temperature 150°C
Min Operating Temperature -40°C
Base Part Number DSEI2X
Element Configuration Dual
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 2.2mA @ 1200V
Voltage - Forward (Vf) (Max) @ If 2.5V @ 60A
Forward Current 52A
Max Surge Current 500A
Voltage - DC Reverse (Vr) (Max) 1200V
Current - Average Rectified (Io) 52A
Forward Voltage 2.5V
Max Reverse Voltage (DC) 1.2kV
Average Rectified Current 52A
Reverse Recovery Time 60 ns
Peak Reverse Current 2.2mA
Max Repetitive Reverse Voltage (Vrrm) 1.2kV
Peak Non-Repetitive Surge Current 500A
Reverse Voltage 1.2kV
Diode Configuration 2 Independent
Max Forward Surge Current (Ifsm) 500A
Recovery Time 60 ns
Dimensions
Height 9mm
Length 47mm
Width 30.3mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
