DSB40C15PB
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 15V TO220AB
PDF
/
Inventory: 2105
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Application SOFT RECOVERY
Forward Voltage 390mV
Max Reverse Voltage (DC) 15V
Average Rectified Current 20A
Number of Phases 1
Max Repetitive Reverse Voltage (Vrrm) 15V
JEDEC-95 Code TO-220AB
Diode Configuration 1 Pair Common Cathode
Max Forward Surge Current (Ifsm) 160A
Max Surge Current 160A
Operating Temperature - Junction -55°C~150°C
Max Reverse Leakage Current 10μA
Forward Current 20A
Voltage - Forward (Vf) (Max) @ If 480mV @ 20A
Current - Reverse Leakage @ Vr 10μA @ 15V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
Qualification Status Not Qualified
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE, LOW NOISE
Min Operating Temperature -55°C
Max Operating Temperature 150°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2004
Packaging Tube
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 28 Weeks
