DSA30C45PC-TRL
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SCHOTTKY 45V TO263
PDF
/
Inventory: 5407
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Surface Mount YES
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Additional Feature FREE WHEELING DIODE, HIGH RELIABILITY, LOW NOISE, PD-CASE
Terminal Position SINGLE
Terminal Form GULL WING
Reference Standard IEC-60747
JESD-30 Code R-PSSO-G2
Operating Temperature (Max) 150°C
Number of Elements 2
Power Dissipation-Max 85W
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 250μA @ 45V
Voltage - Forward (Vf) (Max) @ If 750mV @ 15A
Operating Temperature - Junction -55°C~175°C
Output Current-Max 7.5A
Application SOFT RECOVERY
Voltage - DC Reverse (Vr) (Max) 45V
Current - Average Rectified (Io) 15A
Number of Phases 1
Rep Pk Reverse Voltage-Max 45V
Non-rep Pk Forward Current-Max 340A
Diode Configuration 1 Pair Common Cathode
Reverse Current-Max 250μA
Compliance
RoHS Status ROHS3 Compliant
