DSA20C200PB
RoHS
/
Package TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
PWR DIODE DISC-SCHOTTKYTO-220AB/
PDF
/
Inventory: 3592
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Reverse Current-Max 200μA
Diode Configuration 1 Pair Common Cathode
Non-rep Pk Forward Current-Max 220A
JEDEC-95 Code TO-220AB
Rep Pk Reverse Voltage-Max 200V
Number of Phases 1
Current - Average Rectified (Io) 10A
Voltage - DC Reverse (Vr) (Max) 200V
Application GENERAL PURPOSE
Operating Temperature - Junction -55°C~175°C
Voltage - Forward (Vf) (Max) @ If 910mV @ 10A
Current - Reverse Leakage @ Vr 200μA @ 200V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Power Dissipation-Max 65W
Number of Elements 2
Operating Temperature (Max) 150°C
JESD-30 Code R-PSFM-T3
Reference Standard IEC-60747
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Additional Feature FREE WHEELING DIODE, HIGH RELIABILITY, PD-CASE
Number of Terminations 3
Part Status Active
Series DSA20C200PB
Physical
Diode Element Material SILICON
Surface Mount NO
Package / Case TO-220-3
Mounting Type Through Hole
Supply Chain
Factory Lead Time 28 Weeks
