DHG60C600HB
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY GP 600V 30A TO247AD
PDF
/
Buying Options
Total Price: USD $16.24
Unit Price: USD $16.236
≥1 USD $16.236
≥10 USD $13.14221
≥100 USD $12.36928
≥500 USD $11.209634
Inventory: 49
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Recovery Time 40 ns
Max Forward Surge Current (Ifsm) 200A
Diode Configuration 1 Pair Common Cathode
JEDEC-95 Code TO-247AD
Max Repetitive Reverse Voltage (Vrrm) 600V
Reverse Recovery Time 35 ns
Number of Phases 1
Average Rectified Current 30A
Max Reverse Voltage (DC) 600V
Forward Voltage 2.36V
Application FAST SOFT RECOVERY
Max Surge Current 200A
Operating Temperature - Junction -55°C~150°C
Max Reverse Leakage Current 2mA
Forward Current 30A
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 2.36V @ 30A
Current - Reverse Leakage @ Vr 50μA @ 600V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
Qualification Status Not Qualified
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Max Power Dissipation 180W
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE, SNUBBER DIODE
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Terminal Finish PURE TIN
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2011
Packaging Tube
Physical
Diode Element Material SILICON
Weight 6.500007g
Number of Pins 3
Package / Case TO-247-3
Mounting Type Through Hole
Mount Radial, Through Hole
Supply Chain
Factory Lead Time 20 Weeks
