DHG20C600QB
RoHS
RoHS compliant
RoHS compliantPackage TO-3P-3, SC-65-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY GP 600V 10A TO3P
PDF
/
Buying Options
Total Price: USD $3.56
Unit Price: USD $3.5568
≥1 USD $3.5568
≥10 USD $2.9184
≥100 USD $2.8272
≥500 USD $2.736
≥1000 USD $2.6448
Inventory: 7573
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Recovery Time 35 ns
Diode Configuration 1 Pair Common Cathode
Reverse Recovery Time 35 ns
Number of Phases 1
Average Rectified Current 10A
Max Reverse Voltage (DC) 600V
Application FAST SOFT RECOVERY
Max Surge Current 100A
Operating Temperature - Junction -55°C~150°C
Max Reverse Leakage Current 1.5mA
Voltage - Forward (Vf) (Max) @ If 2.35V @ 10A
Current - Reverse Leakage @ Vr 15μA @ 600V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
Qualification Status Not Qualified
JESD-30 Code R-PSFM-T3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Max Power Dissipation 70W
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE, LOW LEAKAGE CURRENT, SNUBBER DIODE
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2006
Packaging Tube
Physical
Diode Element Material SILICON
Weight 5.500006g
Package / Case TO-3P-3, SC-65-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 20 Weeks
