IDW30S120FKSA1
RoHS
/
Package TO-247-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
CoolSiC?+ Tube Through Hole Silicon Carbide Schottky Diode Array 1.8V @ 30A 15A 150W 1.8V
PDF
/
Inventory: 4361
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Diode Configuration 1 Pair Common Cathode
Peak Non-Repetitive Surge Current 146A
Max Repetitive Reverse Voltage (Vrrm) 1.2kV
Peak Reverse Current 610μA
Number of Phases 1
Average Rectified Current 15A
Max Reverse Voltage (DC) 1.2kV
Forward Voltage 1.8V
Current - Average Rectified (Io) 15A DC
Voltage - DC Reverse (Vr) (Max) 1200V
Application EFFICIENCY
Operating Temperature - Junction -55°C~175°C
Forward Current 30A
Voltage - Forward (Vf) (Max) @ If 1.8V @ 30A
Current - Reverse Leakage @ Vr 305μA @ 1200V
Diode Type Silicon Carbide Schottky
Speed No Recovery Time > 500mA (Io)
Element Configuration Common Cathode
Power Dissipation-Max 150W
Number of Elements 2
JESD-30 Code R-PSFM-T3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
HTS Code 8541.10.00.80
Additional Feature HIGH RELIABILITY
Min Operating Temperature -55°C
Max Operating Temperature 175°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series CoolSiC?+
Published 2014
Packaging Tube
Physical
Package / Case TO-247-3
Mounting Type Through Hole
Mount Through Hole
