BAS28WH6327XTSA1
RoHS
RoHS compliant
RoHS compliantPackage SC-82A, SOT-343
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Tape & Reel (TR) Surface Mount Standard 2Independent Diode Array 1.25V @ 150mA 200mA 0.25W 4ns
PDF
/
Buying Options
Total Price: USD $0.15
Unit Price: USD $0.1482
≥1 USD $0.1482
≥10 USD $0.1216
≥100 USD $0.1178
≥500 USD $0.114
≥1000 USD $0.1102
Inventory: 1199
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 1.25mm
Length 2mm
Height 800μm
Technical
Reverse Test Voltage 75V
Reverse Current-Max 50μA
Diode Configuration 2 Independent
Peak Non-Repetitive Surge Current 4.5A
Max Repetitive Reverse Voltage (Vrrm) 85V
Reverse Recovery Time 4 ns
Average Rectified Current 200mA
Max Reverse Voltage (DC) 80V
Forward Voltage 1.25V
Current - Average Rectified (Io) 200mA DC
Halogen Free Halogen Free
Operating Temperature - Junction 150°C Max
Forward Current 200mA
Voltage - Forward (Vf) (Max) @ If 1.25V @ 150mA
Current - Reverse Leakage @ Vr 100nA @ 75V
Diode Type Standard
Speed Small Signal =< 200mA (Io), Any Speed
Element Configuration Dual
Power Dissipation-Max 0.25W
Base Part Number BAS28
Subcategory Other Diodes
Min Operating Temperature -55°C
Max Operating Temperature 150°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Last Time Buy
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Number of Pins 4
Package / Case SC-82A, SOT-343
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
