MUR20005CTR
RoHS
RoHS compliant
RoHS compliantPackage Twin Tower
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Rectifiers SI S-FST RECOV 2TWR 50-600V 200A 50P/35R
PDF
/
Inventory: 6559
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status PRODUCTION (Last Updated: 4 months ago)
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case Twin Tower
Diode Element Material SILICON
Technical
Packaging Bulk
Published 2010
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Position UPPER
Terminal Form UNSPECIFIED
JESD-30 Code R-PUFM-X2
Operating Temperature (Max) 175°C
Number of Elements 2
Element Configuration Common Anode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 25μA @ 50V
Voltage - Forward (Vf) (Max) @ If 1.3V @ 100A
Operating Temperature - Junction -55°C~150°C
Max Surge Current 800A
Output Current-Max 100A
Application SUPER FAST RECOVERY
Current - Average Rectified (Io) 200A DC
Max Reverse Voltage (DC) 50V
Average Rectified Current 200A
Number of Phases 1
Reverse Recovery Time 75 ns
Peak Reverse Current 25μA
Reverse Voltage 50V
Diode Configuration 1 Pair Common Anode
Compliance
RoHS Status RoHS Compliant
