MBRT50035
RoHS
RoHS compliant
RoHS compliantPackage Three Tower
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Schottky Diodes & Rectifiers SI PWR SCHOTTKY 3TWR 20-100V 500A 35P/25R
PDF
/
Inventory: 7632
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Diode Configuration 1 Pair Common Cathode
Max Repetitive Reverse Voltage (Vrrm) 35V
Peak Reverse Current 1A
Number of Phases 1
Average Rectified Current 500A
Max Reverse Voltage (DC) 35V
Current - Average Rectified (Io) 500A DC
Application POWER
Output Current-Max 250A
Max Surge Current 3.5kA
Max Reverse Leakage Current 1μA
Forward Current 500A
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 750mV @ 250A
Current - Reverse Leakage @ Vr 1mA @ 20V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Number of Elements 2
JESD-30 Code R-PUFM-X3
Terminal Form UNSPECIFIED
Terminal Position UPPER
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Packaging Bulk
Physical
Diode Element Material SILICON
Package / Case Three Tower
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 6 months ago)
Factory Lead Time 6 Weeks
