MBRT40020R
RoHS
RoHS compliant
RoHS compliantPackage Three Tower
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Schottky Diodes & Rectifiers SI PWR SCHOTTKY 3TWR 20-100V 400A 20P/14R
PDF
/
Buying Options
Total Price: USD $226.43
Unit Price: USD $226.42536
≥1 USD $226.42536
≥200 USD $90.345901
≥480 USD $87.326231
≥1000 USD $85.834776
Inventory: 9431
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Diode Configuration 1 Pair Common Anode
Max Repetitive Reverse Voltage (Vrrm) 20V
Peak Reverse Current 1A
Number of Phases 1
Average Rectified Current 400A
Max Reverse Voltage (DC) 20V
Current - Average Rectified (Io) 400A DC
Application POWER
Output Current-Max 200A
Max Surge Current 3kA
Operating Temperature - Junction -55°C~175°C
Max Reverse Leakage Current 1μA
Forward Current 400A
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 750mV @ 200A
Current - Reverse Leakage @ Vr 1mA @ 20V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Number of Elements 2
JESD-30 Code R-PUFM-X3
Terminal Form UNSPECIFIED
Terminal Position UPPER
HTS Code 8541.10.00.80
Min Operating Temperature -40°C
Max Operating Temperature 150°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2012
Packaging Bulk
Physical
Diode Element Material SILICON
Package / Case Three Tower
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 5 months ago)
Factory Lead Time 6 Weeks
