MBRT20060R
RoHS
RoHS compliant
RoHS compliantPackage Three Tower
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Schottky Diodes & Rectifiers 60V 200A Schottky Recovery
PDF
/
Buying Options
Total Price: USD $269.82
Unit Price: USD $269.824582
≥1 USD $269.824582
≥200 USD $107.661739
≥480 USD $104.064393
≥1000 USD $102.286726
Inventory: 1519
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status PRODUCTION (Last Updated: 6 months ago)
Physical
Mount Chassis Mount, Through Hole
Mounting Type Chassis Mount
Package / Case Three Tower
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Bulk
Published 2003
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Max Operating Temperature 150°C
Min Operating Temperature -40°C
HTS Code 8541.10.00.80
Pitch 2.54mm
Terminal Position UPPER
Orientation Straight
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Contacts 6
Number of Elements 2
Max Voltage Rating (AC) 150V
Element Configuration Common Anode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 1mA @ 20V
Voltage - Forward (Vf) (Max) @ If 800mV @ 100A
Case Connection ISOLATED
Forward Current 200A
Max Reverse Leakage Current 1μA
Max Surge Current 1.5kA
Output Current-Max 100A
Application POWER
Current - Average Rectified (Io) 200A DC
Forward Voltage 800mV
Max Reverse Voltage (DC) 60V
Average Rectified Current 200A
Number of Phases 1
Peak Reverse Current 1A
Max Repetitive Reverse Voltage (Vrrm) 60V
Diode Configuration 1 Pair Common Anode
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
