MBRF60020R
RoHS
/
Package TO-244AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Schottky Rectifier - 20 V - 600 A - TO-244AB
PDF
/
Inventory: 2462
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Diode Configuration 1 Pair Common Anode
Max Repetitive Reverse Voltage (Vrrm) 20V
Peak Reverse Current 1A
Number of Phases 1
Average Rectified Current 300A
Max Reverse Voltage (DC) 20V
Application POWER
Operating Temperature - Junction -40°C~175°C
Forward Current 600A
Voltage - Forward (Vf) (Max) @ If 650mV @ 300A
Current - Reverse Leakage @ Vr 10mA @ 20V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Anode
Number of Elements 2
Operating Temperature (Max) 150°C
JESD-30 Code R-PUFM-X2
Terminal Form UNSPECIFIED
Terminal Position UPPER
HTS Code 8541.10.00.80
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2013
Packaging Bulk
Physical
Diode Element Material SILICON
Package / Case TO-244AB
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Factory Lead Time 7 Weeks
