MBR40060CTR
RoHS
RoHS compliant
RoHS compliantPackage Twin Tower
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Schottky Diodes & Rectifiers 60V 400A Schottky Recovery
PDF
/
Buying Options
Total Price: USD $188.95
Unit Price: USD $188.947316
≥1 USD $188.947316
≥200 USD $75.39197
≥480 USD $72.872515
≥1000 USD $71.627885
Inventory: 6800
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status PRODUCTION (Last Updated: 6 months ago)
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case Twin Tower
Diode Element Material SILICON
Technical
Packaging Bulk
Published 2012
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Diode Configuration 1 Pair Common Anode
Max Repetitive Reverse Voltage (Vrrm) 60V
Peak Reverse Current 1A
Number of Phases 1
Average Rectified Current 400A
Max Reverse Voltage (DC) 60V
Current - Average Rectified (Io) 400A DC
Application POWER
Output Current-Max 200A
Max Surge Current 3kA
Max Reverse Leakage Current 1μA
Forward Current 400A
Voltage - Forward (Vf) (Max) @ If 800mV @ 200A
Current - Reverse Leakage @ Vr 5mA @ 20V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Number of Elements 2
JESD-30 Code R-PUFM-X2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UPPER
Min Operating Temperature -40°C
Max Operating Temperature 175°C
Compliance
RoHS Status RoHS Compliant
