MBR30045CT
RoHS
RoHS compliant
RoHS compliantPackage Twin Tower
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Schottky Diodes & Rectifiers 45V 300A Schottky Recovery
PDF
/
Buying Options
Total Price: USD $180.7
Unit Price: USD $180.700992
≥1 USD $180.700992
≥200 USD $72.101842
≥480 USD $69.691358
≥1000 USD $68.50187
Inventory: 994
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Max Forward Surge Current (Ifsm) 2.5kA
Diode Configuration 1 Pair Common Cathode
Max Repetitive Reverse Voltage (Vrrm) 45V
Peak Reverse Current 1μA
Number of Phases 1
Average Rectified Current 300A
Max Reverse Voltage (DC) 45V
Forward Voltage 750mV
Current - Average Rectified (Io) 300A DC
Application POWER
Output Current-Max 150A
Forward Current 300A
Voltage - Forward (Vf) (Max) @ If 650mV @ 150A
Current - Reverse Leakage @ Vr 8mA @ 20V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Number of Elements 2
JESD-30 Code R-PUFM-X2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UPPER
Min Operating Temperature -40°C
Max Operating Temperature 175°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2012
Packaging Bulk
Physical
Diode Element Material SILICON
Package / Case Twin Tower
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 6 months ago)
Factory Lead Time 6 Weeks
