SBR30A60CTB-13
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
DIODE ARRAY SBR 60V 15A D2PAK
PDF
/
Buying Options
Total Price: USD $1.3
Unit Price: USD $1.3024
≥1 USD $1.3024
≥10 USD $1.06832
≥100 USD $0.830544
Inventory: 1080
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Number of Pins 3
Weight 2.239612mg
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Published 2012
Series SBR?
JESD-609 Code e3
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 150°C
Min Operating Temperature -65°C
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number SBR30A60CT
Pin Count 3
JESD-30 Code R-PSSO-G2
Number of Elements 2
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Super Barrier
Current - Reverse Leakage @ Vr 500μA @ 60V
Voltage - Forward (Vf) (Max) @ If 630mV @ 15A
Forward Current 30A
Operating Temperature - Junction -65°C~150°C
Application SUPER FAST SOFT RECOVERY
Forward Voltage 560mV
Max Reverse Voltage (DC) 60V
Average Rectified Current 15A
Number of Phases 1
Peak Reverse Current 100mA
Max Repetitive Reverse Voltage (Vrrm) 60V
Peak Non-Repetitive Surge Current 180A
Diode Configuration 1 Pair Common Cathode
Max Forward Surge Current (Ifsm) 180A
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
