SBL1660CT
RoHS
/
Package TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Tube Through Hole Schottky 1Pair Common Cathode Diode Array 700mV @ 8A 16A 700mV 150C
PDF
/
Buying Options
Total Price: USD $0.17
Unit Price: USD $0.16625
≥1 USD $0.16625
≥10 USD $0.1368
≥100 USD $0.13205
≥500 USD $0.12825
≥1000 USD $0.1235
Inventory: 232
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 4.82mm
Length 10.4mm
Height 8.89mm
Technical
Max Forward Surge Current (Ifsm) 250A
Diode Configuration 1 Pair Common Cathode
Peak Non-Repetitive Surge Current 250A
JEDEC-95 Code TO-220AB
Max Repetitive Reverse Voltage (Vrrm) 60V
Peak Reverse Current 500μA
Number of Phases 1
Average Rectified Current 16A
Max Reverse Voltage (DC) 60V
Forward Voltage 700mV
Application EFFICIENCY
Operating Temperature - Junction -65°C~150°C
Forward Current 16A
Voltage - Forward (Vf) (Max) @ If 700mV @ 8A
Current - Reverse Leakage @ Vr 500μA @ 60V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 40
Peak Reflow Temperature (Cel) 260
Terminal Position SINGLE
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE, LOW POWER LOSS
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e3
Published 2005
Packaging Tube
Physical
Diode Element Material SILICON
Weight 6.000006g
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
