MBR2060CTF-E1
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Automotive AEC-Q101 Bulk Through Hole Schottky Diode Array 810mV @ 10A 10A 60V -55C~150C
PDF
/
Buying Options
Total Price: USD $13.2
Unit Price: USD $13.19835
≥1 USD $13.19835
≥10 USD $10.83
≥100 USD $10.49085
≥500 USD $10.15265
≥1000 USD $9.81445
Inventory: 1225
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Diode Configuration 1 Pair Common Cathode
Average Rectified Current 10A
Max Reverse Voltage (DC) 60V
Current - Average Rectified (Io) 10A
Voltage - DC Reverse (Vr) (Max) 60V
Operating Temperature - Junction -55°C~150°C
Voltage - Forward (Vf) (Max) @ If 810mV @ 10A
Current - Reverse Leakage @ Vr 100μA @ 60V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series Automotive, AEC-Q101
Published 2015
Packaging Bulk
Physical
Supplier Device Package TO-220AB
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 5 Weeks
