M5060THC1200
RoHS
/
Package /
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
RECTIFIER DIODE COMMON CATHODE 3ELEMENTS 4 UL RECOGNIZED Diode Array 800A 1.35V 125C
PDF
/
Buying Options
Total Price: USD $64.17
Unit Price: USD $64.1696
≥1 USD $64.1696
Inventory: 52
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Forward Voltage-Max 1.35V
Non-rep Pk Forward Current-Max 800A
Rep Pk Reverse Voltage-Max 1200V
Number of Phases 1
Application GENERAL PURPOSE
Output Current-Max 60A
Case Connection ISOLATED
Diode Type RECTIFIER DIODE
Configuration COMMON CATHODE, 3 ELEMENTS
Number of Elements 3
Operating Temperature (Min) -40°C
Operating Temperature (Max) 125°C
Qualification Status Not Qualified
JESD-30 Code R-XUFM-X4
Pin Count 4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UPPER
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature UL RECOGNIZED
Terminal Finish Tin (Sn)
ECCN Code EAR99
JESD-609 Code e3
Physical
Number of Terminals 4
Diode Element Material SILICON
Surface Mount NO
