CDBV6-54SD-G
RoHS
RoHS compliant
RoHS compliantPackage 6-TSSOP, SC-88, SOT-363
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Tape & Reel (TR) Surface Mount Schottky 2Pair Series Connection Diode Array 1V @ 100mA 200mA 0.2W 5ns
PDF
/
Inventory: 8104
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-TSSOP, SC-88, SOT-363
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Published 2012
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Subcategory Signal Diodes
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 30
JESD-30 Code R-PDSO-G6
Operating Temperature (Max) 125°C
Number of Elements 2
Power Dissipation-Max 0.2W
Speed Small Signal =< 200mA (Io), Any Speed
Diode Type Schottky
Current - Reverse Leakage @ Vr 2μA @ 25V
Voltage - Forward (Vf) (Max) @ If 1V @ 100mA
Operating Temperature - Junction -65°C~125°C
Output Current-Max 0.2A
Current - Average Rectified (Io) 200mA DC
Max Reverse Voltage (DC) 30V
Average Rectified Current 200mA
Reverse Recovery Time 5ns
Diode Configuration 2 Pair Series Connection
Reverse Current-Max 2μA
Reverse Test Voltage 25V
Compliance
RoHS Status ROHS3 Compliant
