VS-GBPC2506A
RoHS
RoHS compliant
RoHS compliantPackage 4-Square, GBPC-A
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
Bridge Rectifiers 600 Volt 25 Amp
PDF
/
Buying Options
Total Price: USD $5.76
Unit Price: USD $5.764
≥1 USD $5.764
≥10 USD $4.93856
≥100 USD $4.599584
≥500 USD $4.115584
≥1000 USD $3.87347
≥3000 USD $3.631373
Inventory: 64
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 28 Weeks
Physical
Mount Screw
Mounting Type QC Terminal
Package / Case 4-Square, GBPC-A
Number of Pins 4
Weight 14.999988g
Diode Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tray
Published 2014
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
Termination Quick Connect
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Additional Feature UL RECOGNIZED
Technology Standard
Terminal Position UPPER
Terminal Form SOLDER LUG
Base Part Number GBPC2506
Voltage - Rated AC 420V
Number of Elements 1
Element Configuration Single
Diode Type Single Phase
Current - Reverse Leakage @ Vr 2mA @ 600V
Case Connection ISOLATED
Forward Current 25A
Max Surge Current 420A
Forward Voltage 1.1V
Number of Phases 1
Peak Reverse Current 5μA
Max Repetitive Reverse Voltage (Vrrm) 600V
Peak Non-Repetitive Surge Current 420A
Max Forward Surge Current (Ifsm) 420A
Isolation Voltage 2.7kV
Dimensions
Height 7.7mm
Length 28.6mm
Width 28.6mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
