VS-160MT120KPBF
RoHS
RoHS compliant
RoHS compliantPackage MT-K Module
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
Diode Rectifier Bridge Single 1.2KV 200A 6-Pin INT-A-PAK
PDF
/
Buying Options
Total Price: USD $72.86
Unit Price: USD $72.864
≥1 USD $72.864
≥10 USD $66.51744
≥100 USD $60.171047
Inventory: 75
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Chassis Mount, Panel, Screw
Mounting Type Chassis Mount
Package / Case MT-K Module
Number of Pins 6
Diode Element Material SILICON
Technical
Operating Temperature -40°C~150°C TJ
Packaging Bulk
Published 2006
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Additional Feature UL RECOGNIZED
Technology Standard
Terminal Position UPPER
Terminal Form UNSPECIFIED
Number of Elements 1
Element Configuration Single
Diode Type Three Phase
Case Connection ISOLATED
Forward Current 160A
Max Reverse Leakage Current 10mA
Max Surge Current 1.5kA
Forward Voltage 1.49V
Number of Phases 3
Peak Reverse Current 10mA
Max Repetitive Reverse Voltage (Vrrm) 1.2kV
Peak Non-Repetitive Surge Current 1.5kA
Max Forward Surge Current (Ifsm) 1.5kA
Dimensions
Height 30mm
Length 94mm
Width 35mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
