KBP005M-E4/51
RoHS
RoHS compliant
RoHS compliantPackage 4-SIP, KBPM
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
BRIDGE RECT 1PHASE 50V 1.5A KBPM
PDF
/
Inventory: 3227
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 5.08mm
Length 15.24mm
Height 11.68mm
Technical
Peak Non-Repetitive Surge Current 60A
Max Repetitive Reverse Voltage (Vrrm) 50V
Peak Reverse Current 5μA
Number of Phases 1
Forward Voltage 1.3V
Current - Average Rectified (Io) 1.5A
Max Surge Current 60A
Max Reverse Leakage Current 5μA
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 1V @ 1A
Current - Reverse Leakage @ Vr 5μA @ 50V
Diode Type Single Phase
Element Configuration Single
Number of Elements 1
Pin Count 4
Base Part Number KBP005
Technology Standard
Subcategory Bridge Rectifier Diodes
Additional Feature UL RECOGNIZED
Terminal Finish Silver (Ag)
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Published 2011
Packaging Bulk
Operating Temperature -55°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 4
Package / Case 4-SIP, KBPM
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 22 Weeks
