GBPC2510-E4/51
RoHS
RoHS compliant
RoHS compliantPackage 4-Square, GBPC
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
Diode Rectifier Bridge Single 1KV 25A 4-Pin Case GBPC Bulk
PDF
/
Buying Options
Total Price: USD $3.12
Unit Price: USD $3.124
≥1 USD $3.124
≥10 USD $2.62504
≥100 USD $2.123792
≥500 USD $2.07724
Inventory: 1097
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Screw
Mounting Type QC Terminal
Package / Case 4-Square, GBPC
Number of Pins 4
Diode Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Bulk
Published 2014
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
Terminal Finish Nickel (Ni)
Additional Feature UL RECOGNIZED
Subcategory Bridge Rectifier Diodes
Technology Standard
Terminal Position UPPER
Terminal Form SOLDER LUG
Base Part Number GBPC2510
Pin Count 4
Number of Elements 1
Element Configuration Single
Diode Type Single Phase
Current - Reverse Leakage @ Vr 5μA @ 1000V
Voltage - Forward (Vf) (Max) @ If 1.1V @ 12.5A
Case Connection ISOLATED
Forward Current 25A
Max Reverse Leakage Current 5μA
Max Surge Current 300A
Forward Voltage 1.1V
Average Rectified Current 25A
Number of Phases 1
Peak Reverse Current 5μA
Max Repetitive Reverse Voltage (Vrrm) 1kV
Peak Non-Repetitive Surge Current 300A
Dimensions
Height 7.62mm
Length 28.8mm
Width 28.8mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
