MDB8S
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, Gull Wing
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
Bridge Rectifiers 1A Bridge Rectifier
PDF
/
Buying Options
Total Price: USD $0.44
Unit Price: USD $0.44
≥1 USD $0.44
≥10 USD $0.37928
≥100 USD $0.263472
≥500 USD $0.205691
≥1000 USD $0.167182
≥3000 USD $0.14945
Inventory: 12601
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 hours ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 4-SMD, Gull Wing
Number of Pins 4
Weight 270mg
Diode Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Published 2013
Tolerance 10%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
ECCN Code EAR99
Terminal Finish Tin (Sn)
Voltage - Rated 10V
Capacitance 4.7μF
Subcategory Bridge Rectifier Diodes
Technology Standard
Terminal Position DUAL
Base Part Number MDB8
Case Code (Metric) 3216
Case Code (Imperial) 1206
Lead Pitch 7.493mm
Number of Elements 1
Element Configuration Single
Diode Type Single Phase
Current - Reverse Leakage @ Vr 10μA @ 800V
Voltage - Forward (Vf) (Max) @ If 1.1V @ 1A
Forward Current 1A
Lead/Base Style Straight
Max Reverse Leakage Current 10μA
Max Surge Current 30A
Output Current-Max 1A
Forward Voltage 1.1V
Number of Phases 1
Peak Reverse Current 10μA
Max Repetitive Reverse Voltage (Vrrm) 800V
Peak Non-Repetitive Surge Current 30A
Max Forward Surge Current (Ifsm) 30A
Dimensions
Height 1.45mm
Height Seated (Max) 8.001mm
Length 3.2004mm
Width 1.6002mm
Thickness 1.8034mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
