MB1S
RoHS
RoHS compliant
RoHS compliantPackage TO-269AA, 4-BESOP
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
Diode Rectifier Bridge Single 100V 0.5A 4-Pin SOIC N T/R
PDF
/
Buying Options
Total Price: USD $0.45
Unit Price: USD $0.4488
≥1 USD $0.4488
≥10 USD $0.34496
≥100 USD $0.207064
≥500 USD $0.191752
≥1000 USD $0.130398
Inventory: 67070
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-269AA, 4-BESOP
Number of Pins 4
Supplier Device Package 4-SOIC
Weight 228mg
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Published 2014
Tolerance 10%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Voltage - Rated 16V
Capacitance 13pF
Voltage - Rated DC 100V
Max Power Dissipation 1.4W
Technology Standard
Current Rating 500mA
Base Part Number MB1
Case Code (Metric) 1608
Case Code (Imperial) 0603
Number of Elements 1
Element Configuration Single
Diode Type Single Phase
Current - Reverse Leakage @ Vr 5μA @ 100V
Power Dissipation 1.4W
Output Current 500mA
Voltage - Forward (Vf) (Max) @ If 1V @ 500mA
Forward Current 500mA
Max Reverse Leakage Current 5μA
Max Surge Current 35A
Current - Average Rectified (Io) 500mA
Forward Voltage 1V
Average Rectified Current 500mA
Peak Reverse Current 5μA
Max Repetitive Reverse Voltage (Vrrm) 100V
Peak Non-Repetitive Surge Current 35A
Reverse Voltage 100V
Max Forward Surge Current (Ifsm) 35A
Voltage - Peak Reverse (Max) 100V
Max Junction Temperature (Tj) 150°C
Dimensions
Height 2.9mm
Length 3.2004mm
Width 4.2mm
Thickness 939.8μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
