KBU8A
RoHS
/
Package 4-SIP, KBU
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
Bulk Through Hole Single Phase Standard Bridge Rectifier 1V @ 8A 8A 6.9W 1V
PDF
/
Buying Options
Total Price: USD $2.5
Unit Price: USD $2.50049
≥1 USD $2.50049
≥10 USD $2.358951
≥100 USD $2.225425
≥500 USD $2.099458
≥1000 USD $1.980618
Inventory: 1234
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 4-SIP, KBU
Number of Pins 4
Supplier Device Package KBU
Technical
Operating Temperature -55°C~150°C TJ
Packaging Bulk
Published 2010
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Voltage - Rated DC 50V
Technology Standard
Current Rating 8A
Base Part Number KBU8A
Number of Elements 1
Diode Type Single Phase
Current - Reverse Leakage @ Vr 10μA @ 50V
Power Dissipation 6.9W
Output Current 8A
Voltage - Forward (Vf) (Max) @ If 1V @ 8A
Max Reverse Leakage Current 10μA
Max Surge Current 300A
Current - Average Rectified (Io) 8A
Forward Voltage 1V
Peak Non-Repetitive Surge Current 300A
Voltage - Peak Reverse (Max) 50V
Dimensions
Height 19.3mm
Length 23.7mm
Width 7.1mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
