KBU6M
RoHS
/
Package 4-SIP, KBU
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
Bulk Through Hole Single Phase Standard Bridge Rectifier 1V @ 6A 6A 6.7W 1V
PDF
/
Buying Options
Total Price: USD $1.55
Unit Price: USD $1.5488
≥1 USD $1.5488
≥10 USD $1.1528
≥100 USD $1.02432
≥500 USD $0.85624
≥1000 USD $0.7612
≥3000 USD $0.69608
Inventory: 1130
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 4-SIP, KBU
Number of Pins 4
Supplier Device Package KBU
Weight 9.00001g
Technical
Operating Temperature -55°C~150°C TJ
Packaging Bulk
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Voltage - Rated DC 1kV
Technology Standard
Current Rating 6A
Base Part Number KBU6M
Number of Elements 1
Diode Type Single Phase
Current - Reverse Leakage @ Vr 5μA @ 1000V
Power Dissipation 6.7W
Output Current 6A
Voltage - Forward (Vf) (Max) @ If 1V @ 6A
Max Reverse Leakage Current 5μA
Max Surge Current 250A
Current - Average Rectified (Io) 6A
Forward Voltage 1V
Peak Non-Repetitive Surge Current 250A
Voltage - Peak Reverse (Max) 1kV
Dimensions
Height 19.3mm
Length 23.7mm
Width 7.1mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
