KBP01M
RoHS
/
Package 4-SIP, KBPM
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
Tube Through Hole Single Phase Single Bridge Rectifier 1V @ 1A 1.5A 3.5W 1.3V
PDF
/
Buying Options
Total Price: USD $0.45
Unit Price: USD $0.451638
≥1 USD $0.451638
≥200 USD $0.174616
≥500 USD $0.169364
≥1000 USD $0.165425
Inventory: 3034
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 4-SIP, KBPM
Number of Pins 4
Supplier Device Package KBPM
Technical
Operating Temperature -55°C~165°C TJ
Packaging Tube
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Through Hole
Max Operating Temperature 165°C
Min Operating Temperature -55°C
Capacitance 15pF
Voltage - Rated DC 100V
Max Power Dissipation 3.5W
Technology Standard
Current Rating 1.5A
Number of Elements 1
Element Configuration Single
Diode Type Single Phase
Current - Reverse Leakage @ Vr 5μA @ 100V
Power Dissipation 3.5W
Output Current 1.5A
Voltage - Forward (Vf) (Max) @ If 1V @ 1A
Forward Current 1.5A
Max Reverse Leakage Current 5μA
Max Surge Current 50A
Current - Average Rectified (Io) 1.5A
Forward Voltage 1.3V
Peak Reverse Current 5μA
Max Repetitive Reverse Voltage (Vrrm) 100V
Peak Non-Repetitive Surge Current 50A
Voltage - Peak Reverse (Max) 100V
Dimensions
Height 12.7mm
Length 15.24mm
Width 5.08mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
