KBL04
RoHS
/
Package 4-SIP, KBL
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
Bulk Through Hole Single Phase Standard Bridge Rectifier 1.1V @ 4A 4A 6.58W 600V
PDF
/
Buying Options
Total Price: USD $0.38
Unit Price: USD $0.3784
≥1 USD $0.3784
Inventory: 3909
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 4-SIP, KBL
Number of Pins 4
Supplier Device Package KBL
Weight 5.038986g
Technical
Operating Temperature -55°C~150°C TJ
Packaging Bulk
Published 2001
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Voltage - Rated DC 400V
Technology Standard
Current Rating 4A
Base Part Number KBL04
Number of Elements 1
Voltage 600V
Current 4A
Diode Type Single Phase
Current - Reverse Leakage @ Vr 5μA @ 400V
Power Dissipation 6.58W
Output Current 4A
Voltage - Forward (Vf) (Max) @ If 1.1V @ 4A
Max Reverse Leakage Current 5μA
Max Surge Current 200A
Breakdown Voltage 400V
Current - Average Rectified (Io) 4A
Forward Voltage 1.1V
Average Rectified Current 4A
Peak Reverse Current 5μA
Max Repetitive Reverse Voltage (Vrrm) 400V
Peak Non-Repetitive Surge Current 200A
Voltage - Peak Reverse (Max) 400V
Dimensions
Height 16.38mm
Length 19.6mm
Width 6.48mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
