DBG150G
RoHS
/
Package 4-SIP, DBG
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
Bulk Through Hole Single Phase Single Bridge Rectifier 900mV @ 7.5A 3.6A 900mV 150C TJ
PDF
/
Buying Options
Total Price: USD $3.43
Unit Price: USD $3.432
≥1 USD $3.432
Inventory: 1221
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 4-SIP, DBG
Number of Pins 4
Diode Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Bulk
Published 2007
JESD-609 Code e6
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
Terminal Finish Tin/Bismuth (Sn/Bi)
Additional Feature HIGH RELIABILITY
Technology Standard
Pin Count 4
Qualification Status Not Qualified
Number of Elements 1
Element Configuration Single
Diode Type Single Phase
Current - Reverse Leakage @ Vr 10μA @ 600V
Voltage - Forward (Vf) (Max) @ If 900mV @ 7.5A
Case Connection ISOLATED
Forward Current 15A
Output Current-Max 3.6A
Current - Average Rectified (Io) 3.6A
Forward Voltage 900mV
Number of Phases 1
Peak Reverse Current 10μA
Max Repetitive Reverse Voltage (Vrrm) 600V
Peak Non-Repetitive Surge Current 200A
Max Forward Surge Current (Ifsm) 200A
Compliance
RoHS Status RoHS Compliant
