VUO64-16NO7
RoHS
RoHS compliant
RoHS compliantPackage PWS-D
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
Bridge Rectifiers Standard Rectifier Module BipolarBridge
PDF
/
Buying Options
Total Price: USD $76.01
Unit Price: USD $76.00772
≥1 USD $76.00772
≥200 USD $30.32799
≥500 USD $29.314431
≥1000 USD $28.814216
Inventory: 9811
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Voltage - Peak Reverse (Max) 1.6kV
Non-rep Pk Forward Current-Max 505A
Number of Phases 3
Current - Average Rectified (Io) 60A
Output Current-Max 72A
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 1.3V @ 60A
Current - Reverse Leakage @ Vr 40μA @ 1600V
Diode Type Three Phase
Configuration BRIDGE, 6 ELEMENTS
Number of Elements 6
Qualification Status Not Qualified
JESD-30 Code R-XUFM-X5
Pin Count 5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UPPER
Technology Standard
Subcategory Bridge Rectifier Diodes
HTS Code 8541.10.00.80
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2012
Packaging Bulk
Operating Temperature -40°C~150°C TJ
Physical
Diode Element Material SILICON
Package / Case PWS-D
Mounting Type Chassis Mount
Mount Chassis Mount
