VBO88-14NO7
RoHS
RoHS compliant
RoHS compliantPackage ECO-PAC2
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
Diode Rectifier Bridge Single 1.4KV 92A 6-Pin ECO-PAC 2
PDF
/
Inventory: 4108
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 34.3mm
Length 51mm
Height 9mm
Technical
Voltage - Peak Reverse (Max) 1.4kV
Non-rep Pk Forward Current-Max 850A
Peak Non-Repetitive Surge Current 990A
Number of Phases 1
Average Rectified Current 92A
Forward Voltage 1.75V
Max Surge Current 1.4kA
Max Reverse Leakage Current 500μA
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 1.75V @ 200A
Current - Reverse Leakage @ Vr 500μA @ 1400V
Diode Type Single Phase
Configuration BRIDGE, 4 ELEMENTS
Number of Elements 1
Qualification Status Not Qualified
Pin Count 6
Base Part Number VBO88
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UPPER
Technology Standard
Subcategory Bridge Rectifier Diodes
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2004
Packaging Bulk
Operating Temperature -40°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 6
Package / Case ECO-PAC2
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
