VBO52-08NO7
RoHS
RoHS compliant
RoHS compliantPackage PWS-D
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
Diode Rectifier Bridge Single 800V 52A 4-Pin PWS-D
PDF
/
Buying Options
Total Price: USD $71.08
Unit Price: USD $71.075154
≥1 USD $71.075154
≥200 USD $28.359953
≥500 USD $27.412039
≥1000 USD $26.943334
Inventory: 1251
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Chassis Mount
Package / Case PWS-D
Surface Mount NO
Diode Element Material SILICON
Technical
Operating Temperature -40°C~150°C TJ
Packaging Bulk
Published 2010
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
HTS Code 8541.10.00.80
Subcategory Bridge Rectifier Diodes
Technology Standard
Terminal Position UPPER
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number VBO52
JESD-30 Code R-PUFM-X4
Qualification Status Not Qualified
Number of Elements 4
Configuration BRIDGE, 4 ELEMENTS
Diode Type Single Phase
Current - Reverse Leakage @ Vr 100μA @ 800V
Voltage - Forward (Vf) (Max) @ If 1.14V @ 40A
Case Connection ISOLATED
Output Current-Max 52A
Current - Average Rectified (Io) 52A
Number of Phases 1
Non-rep Pk Forward Current-Max 550A
Voltage - Peak Reverse (Max) 800V
Compliance
RoHS Status ROHS3 Compliant
