VBO125-16NO7
RoHS
RoHS compliant
RoHS compliantPackage PWS-C
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
Diode Rectifier Bridge Single 1.6KV 124A 4-Pin PWS-C
PDF
/
Buying Options
Total Price: USD $145.23
Unit Price: USD $145.230372
≥1 USD $145.230372
≥200 USD $57.94878
≥500 USD $56.012253
≥1000 USD $55.055149
Inventory: 1636
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 50mm
Length 67mm
Height 31mm
Technical
Max Forward Surge Current (Ifsm) 1.95kA
Peak Non-Repetitive Surge Current 1.95kA
Max Repetitive Reverse Voltage (Vrrm) 1.6kV
Peak Reverse Current 300μA
Number of Phases 1
Forward Voltage 1.3V
Max Surge Current 1.8kA
Max Reverse Leakage Current 300μA
Forward Current 124A
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 1.3V @ 150A
Current - Reverse Leakage @ Vr 300μA @ 1600V
Diode Type Single Phase
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Base Part Number VBO125
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UPPER
Technology Standard
Subcategory Bridge Rectifier Diodes
Additional Feature UL RECOGNIZED
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2010
Packaging Bulk
Operating Temperature -40°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 4
Package / Case PWS-C
Mounting Type Chassis Mount
Mount Chassis Mount, Panel, Screw
Supply Chain
Factory Lead Time 16 Weeks
